KOS Series Small Size OCXO
KOS14D

KOS14D
Performance Index

Frequency Range:40MHz~100MHz
Supply Voltage:5VDC、12VDC(VCC±5%)
Start-up Power Consumption:<2.8W(+25℃,Duration Time <90s)
Steady State Power Consumption:<0.8W(+25℃,Duration Time <300s)
Output Waveform:Sine、LVTTL
Frequency Stability vs Temperature:<±0.1ppm
Short Term Frequency Stability(ADEV):[email protected](Typical Value)
Aging(After 1days of Continuous Operation):<±5E-9/day,<±5E-7/year
Phase Noise(2):<-88dBc/[email protected],<-118dBc/[email protected],<-145dBc/[email protected],<-155dBc/[email protected]
Phase Noise(3):<-90dBc/[email protected],<-120dBc/[email protected],<-150dBc/[email protected],<-160dBc/[email protected]

Operable Temperature Range:-40→+70℃
Storage Temperature Range:-55→+85℃
Size:20.5×12.7×9.2mm
Outline Drawing and Pin Function
14D Outline Drawing.png
